All three types of communications interfaces can be installed and active simultaneously. Optional serial communications are also available configurable as RS232 or RS485, with straightforward ASCII commands or MODBUS®. Optional “embedded ethernet” on the 1⁄16 and 1⁄8 DIN models allow the units to connect directly to an Ethernet network and transmit data in standard TCP/IP packets, or serve Web pages over a LAN or the Internet.

Profiles may be linked to provide extended sequences and auxiliary outputs may be triggered based on individual Ramp or Soak states to provide external control over blowers, mixers or other auxiliary control functions.Įmbedded Ethernet and Serial Communications

Performance Tracking (Charting) with Data CaptureĪn advanced multi-stage ramp and soak sequencer supports up to 99 profiles of 8 segment ramp/soak sequences.

Fully Configure all PLATINUM Functions/Parameters.

Standard features include: remote set-point for cascaded control, high-high/low-low alarms, external latch reset, external ramp and soak initiation, combination heat/cool control mode and configuration save and transfer.įree Downloadable Configurator Windows® Application Software Up to 6 programmable outputs including the isolated analogue and additional features make this the most powerful product in its class. The full bidirectional voltage or current inputs are fully scalable to virtually all engineering units, with a selectable decimal point that is perfect for use with pressure, flow, or other process input.

Offered in 1⁄32, 1⁄16, and 1⁄8 DIN sizes, the 1⁄16 and 1⁄8 DIN models can be configured with dual displays.Įach unit allows the user to select the input type from 9 thermocouple types, PRT/RTD sensors, thermistors, DC voltage, DC current, and Strain & Bridge inputs. The automatic hardware configuration recognition eliminates the need for jumpers and allows the firmware to automatically simplify itself, eliminating all menu options that do not apply to a specific configuration. While extremely powerful and versatile, great care has gone into designing a product that is very easy to set-up and use. The Platinum Series family of microprocessor-based PID controllers offer unparalleled flexibility in process measurement.
